| Material | Tungsten steel/carbide |
| Whether to support customization | YES |
| Hrc | 55°/56°/58°/62°/65° |
| Coating | DLC colorful |
| OEM & ODM | OK |
| Suitable for | aluminum |
Features：
1.High gloss mirror surface
2. Full cutting, large feed
3.U-shaped groove reduces processing time and cost、
4. Multi-layer coating DLC coating, high hardness and fast heat dissipation
U-Slot Spiral End Mill specification table:
d1=Flute Diameter d2=Shank Diameter L1=Overall Length L2=Flute Length
| Flute Diameter(mm)*Flute Length(mm)*Shank Diameter(mm)* Overall Length(mm)*Flute |
| D2.5*5*D4*50L*3F |
| D3*3*D4*50L*3F |
| D3*4*D4*50L*3F |
| D3*6*D4*50L*3F |
| D4*4*50L*3F |
| D4*6*50L*3F |
| D4*8*50L*3F |
| D6*6*50L*3F |
| D6*8*50L*3F |
| D6*10*50L*3F |
| D6*12*50L*3F |
| D8*8*60L*3F |
| D8*10*60L*3F |
| D8*12*60L*3F |
| D8*15*60L*3F |
| D10*10*60L*3F |
| D10*12*60L*3F |
| D10*15*60L*3F |
| D10*18*60L*3F |
| D10*20*60L*3F |
| D12*12*60L*3F |
| D12*15*60L*3F |
| D12*18*60L*3F |
| D12*20*60L*3F |
| D12*24*60L*3F |
Short Flute U-Slot end mills usually have better rigidity and stability and are suitable for withstanding greater cutting forces. Long Flute U-Slot end mills usually have a dense tooth design and are suitable for finishing machining.
