| HRC | 55°56°58°60°62°65° |
| Material | Solid Carbide |
| Customizable | Yes |
| Coating | DLC Colorful/Nano |
Dimensions and specifications：
| Thread | Pitch | size | Chip flute | Recommended bottom hole | |||
| ISO standard flute | mm |
|
Flute Diameter(mm) | Flute Length(mm) | Overall Length(mm) | Z | mm |
| M3＊0 . 5 | 0.5 | 4 | 2.4 | 6 | 50 | 3 | 2.5 |
| M4＊0 . 5 - M5＊0 . 5 | 0.5 | 4 | 3.2 | 8 | 50 | 3 | 3.5 |
| M3 . 5*0 . 6 | 0.6 | 4 | 2.8 | 7 | 50 | 3 | 2.9 |
| M4＊0 . 7 | 0.7 | 4 | 3 . 15 | 8 . 4 | 50 | 3 | 3.3 |
| M6＊0 .75 | 0 . 75 | 4 | 3.9 | 12 | 50 | 3 | 5.3 |
| M8＊0 .75 | 0 . 75 | 6 | 5.9 | 16 | 57 | 3 | 7.3 |
| M5＊0 . 8 | 0.8 | 4 | 3.9 | 10 .4 | 50 | 3 | 4 . 2 |
| M6*1 . 0 | 1 | 6 | 4.8 | 12 | 57 | 3 | 5 |
| M8＊1 . 0 | 1 | 6 | 5.9 | 16 | 57 | 3 | 7 |
| M10＊1 . 0 | 1 | 8 | 7.9 | 20 | 65 | 3 | 9 |
| M12＊1 . 0 | 1 | 10 | 9.9 | 24 | 70 | 4 | 11 |
| M8＊1 . 25 | 1 . 25 | 6 | 5.9 | 16 . 2 | 57 | 3 | 6.8 |
| M10*1 . 25 | 1 . 25 | 8 | 7.9 | 20 | 65 | 3 | 8.8 |
| M10＊1 . 5 | 1.5 | 8 | 7.9 | 19 . 5 | 65 | 3 | 8.5 |
| M12＊1 . 25 | 1 . 25 | 10 | 9.9 | 24 | 70 | 3 | 10 . 8 |
| M12＊1 . 5 | 1.5 | 10 | 9.9 | 24 | 70 | 4 | 10 . 5 |
| M14＊1 . 5 - M16＊1 . 5 | 1.5 | 12 | 11 . 9 | 30 | 75 | 4 | 12 . 5 |
| M12*1 . 75 | 1 . 75 | 10 | 9.9 | 25 | 70 | 4 | 10 . 2 |
| M14＊2 . 0 -M16＊2 . 0 | 2 | 12 | 11.6 | 30 | 75 | 4 | 12 |
| M18＊2 . 5 -M22＊2 . 5 | 2.5 | 14 | 13 . 9 | 40 | 90 | 4 | 15 . 5 |
| M24＊3 . 0 | 3 | 16 | 15 . 9 | 42 | 100 | 4 | 21 |
