| Material | Carbide/Tungsten Steel |
| Flute | 2/4/6 |
| Style | Taper Pin |
| Coating | Titanium Nitride (TiN) |
Key Features:
Titanium Nitride (TiN) Coating & Fully Ground Edge: Features a high-hardness TiN coating and a fully ground cutting edge for superior wear resistance. Constructed as a single-piece solid tungsten steel.
Wide Material Compatibility: Offers versatile cutting performance for both soft and hard materials, including various steels, cast iron, alloy steels, copper, and aluminum alloys. Renowned for its sharpness and durability.
Customization Available: Can be customized to your specific requirements.
Size:
| Specification | Flute Diameter(mm) | Flute Length(mm) | Overall Length(mm) | Flute | Tolerance |
| D2*15*50L*4F-H7 | 2 | 15 | 50 | 4 | 7 |
| D3*20*50L*4F-H7 | 3 | 20 | 50 | 4 | 7 |
| D4*25*50L*4F-H7 | 4 | 25 | 50 | 4 | 7 |
| D5*30*60L*4F-H7 | 5 | 30 | 60 | 4 | 7 |
| D6*30*60L*6F-H7 | 6 | 30 | 60 | 6 | 7 |
| D8*40*75L*6F-H7 | 8 | 40 | 75 | 6 | 7 |
| D10*40*75L*6F-H7 | 10 | 40 | 75 | 6 | 7 |
| D10*50*100L*6F-H7 | 10 | 50 | 100 | 6 | 7 |
| D12*40*75L*6F-H7 | 12 | 40 | 75 | 6 | 7 |
| D12*50*100L*6F-H7 | 12 | 50 | 100 | 6 | 7 |
