| Material | Carbide |
| Number of Flutes | 4 |
| HRC | 45/55/56/65/70 |
| Cut Type | Finishing, Roughing |
| Coating | Customizable |
| Applicable materials | steel, cast iron, stainless steel, etc. |
KEY FEATURES
Premium Imported Tungsten Carbide
Ultra-fine 0.6μm micro-grain structure.
Exceptional wear resistance and strength for high-hardness materials.
Optimized for high-speed, heavy-duty roughing applications.
Enhanced Durability & Corrosion Resistance
Imported passivation technology reduces wear and improves corrosion resistance.
Precision-ground cutting edges: burr-free, smooth, and consistent.
Maximizes tool lifespan even under aggressive cutting conditions.
TECHNICAL SPECIFICATIONS
Material: Tungsten Carbide (WC)
Grain Size: 0.6μm
Max. Tool Runout Tolerance: ≤0.01mm
Cooling Method: Flood coolant or MQL (Minimum Quantity Lubrication) recommended
USAGE GUIDELINES
Pre-Operation Check
Measure tool runout before use. Do not exceed 0.01mm runout tolerance. Correct if necessary.
Tool Setup
Minimize tool overhang from the chuck.
Note: Longer tool extensions require reduced RPM, feed rate, or depth of cut (DOC).
Cutting Parameters
If abnormal vibration or noise occurs:
✓ Immediately reduce RPM.
✓ Decrease feed rate or DOC incrementally until stable.
Cooling Recommendations
Steel Machining: Prioritize flood coolant or high-pressure jet cooling.
Significantly improves tool performance and surface finish.
WARNING
Failure to follow these guidelines may cause tool breakage, poor surface finish, or reduced tool life. Always prioritize stable cutting conditions.
Other sizes available:
| Specifications | Flute Diameter(mm) | Flute Length(mm) | Shank Diameter(mm) | Overall Length(mm) |
| D4*12*50L*4F | 4 | 12 | 4 | 50 |
| D5*15*50*4F | 5 | 15 | 5 | 50 |
| D6*18*50L*4F | 6 | 18 | 6 | 50 |
| D6*24*75L*4F | 6 | 24 | 6 | 50 |
| D6*30*100L*4F | 6 | 30 | 6 | 75 |
| D8*24*60L*4F | 8 | 24 | 8 | 60 |
| D8*30*75L*4F | 8 | 30 | 8 | 75 |
| D8*35*100L*4F | 8 | 35 | 8 | 100 |
| D10*30*75L*4F | 10 | 30 | 10 | 75 |
| D10*45*100L*4F | 10 | 45 | 10 | 100 |
| D10*60*150L*4F | 10 | 60 | 10 | 150 |
| D12*35*75L*4F | 12 | 35 | 12 | 75 |
| D12*45*100[*4F | 12 | 45 | 12 | 100 |
| D14*45*100L*4F | 14 | 45 | 14 | 100 |
| D16*45*100L*4F | 16 | 45 | 16 | 100 |
| D16*70*150L*4F | 16 | 70 | 16 | 150 |
| D18*45*100L*4F | 18 | 45 | 18 | 100 |
| D20*45*100L*4F | 20 | 45 | 20 | 100 |
