| Material | HSS |
| HRC | 60 |
| Applicable | Carbon steel, cast iron, aluminum, brass, copper and stainless steel |
| Customizable | YES |
| Thread direction | Left hand/Right hand |
| Coating | Bright |
FEATURES :
Size:
| Specification | Pitch(mm) | Flute Length(mm) | Overall Length(mm) | Shank Diameter(mm) |
| M1.4*0.3 | 0.3 | 6 | 42 | 3 |
| M1.6*0.35 | 0.35 | 8 | 42 | 3 |
| M1.7*0.35 | 0.35 | 8 | 42 | 3 |
| M1.8*0.35 | 0.35 | 9 | 42 | 3 |
| M2.0*0.4 | 0.4 | 10 | 42 | 3 |
| M2.5*0.45 | 0.45 | 11 | 52 | 4 |
| M3.0*0.5 | 0.5 | 11 | 52 | 4 |
| M3.5*0.6 | 0.6 | 12 | 55 | 5 |
| M4.0*0.7 | 0.7 | 13 | 60 | 5 |
| M5.0*0.8 | 0.8 | 15 | 65 | 6 |
| M6.0*1 | 1 | 16 | 73 | 6.2 |
| M8.0*1 | 1 | 18 | 73 | 6.2 |
| M8.0*1.25 | 1.25 | 18 | 75 | 8 |
| M10*1 | 1 | 21 | 75 | 8 |
| M10*1.25 | 1.25 | 21 | 75 | 8 |
| M10*1.5 | 1.5 | 21 | 83 | 9 |
| M12*1.25 | 1.25 | 25 | 83 | 9 |
| M12*1.5 | 1.5 | 25 | 83 | 9 |
| M12*1.75 | 1.75 | 26 | 90 | 10.5 |
| M14*1.5 | 1.5 | 26 | 90 | 10.5 |
| M14*2 | 2 | 26 | 98 | 12.5 |
| M16*1.5 | 1.5 | 29 | 98 | 12.5 |
| M16*2 | 2 | 29 | 100 | 14 |
