| Material | Tungsten steel |
| HRC | 56 |
| Coating | DLC colorful |
| Applicable | aluminum |
1. Tungsten carbide: It uses micro-grain tungsten steel as the base material, which has high wear resistance and strength. It is a milling cutter for high-hardness and high-speed cutting applications.
2. Full-tang cutting edge is sharp: It is wear-resistant and durable, which effectively guarantees the service life of the milling cutter.
sizes:（Other hardness and size can be consulted）
| Flute Diameter(mm) | Flute Length(mm) | Shank Diameter(mm) | Overall Length(mm) |
| 0.1 | 0.2 | 4 | 50 |
| 0.15 | 0.3 | 4 | 50 |
| 0.2 | 0.4 | 4 | 50 |
| 0.25 | 0.5 | 4 | 50 |
| 0.3 | 0.6 | 4 | 50 |
| 0.35 | 0.7 | 4 | 50 |
| 0.4 | 0.8 | 4 | 50 |
| 0.5 | 1 | 4 | 50 |
| 0.6 | 1.2 | 4 | 50 |
| 0.7 | 1.4 | 4 | 50 |
| 0.8 | 1.6 | 4 | 50 |
| 0.9 | 1.9 | 4 | 50 |
| RO.1 | 0.4 | 4 | 50 |
| R0.15 | 0.6 | 4 | 50 |
| RO.2 | 0.8 | 4 | 50 |
| R0.25 | 1 | 4 | 50 |
| RO.3 | 1.2 | 4 | 50 |
| RO.35 | 1.4 | 4 | 50 |
| RO.4 | 1.6 | 4 | 50 |
| RO.45 | 1.8 | 4 | 50 |
